OR GQG-1800 Laser/UV/IR/LED Portable/Laboratory Forensic Light Source







1800 Silo

OR GQG1800 Pix3 copy

OR GQG1800 Pix1 copy


This Laboratory grade forensic light source has 5 Laser and 5 LED wavelengths available for evidence inspection, and also 940/850/730 nm Infrared, and 415/375/365 nm UV, all of which can be cycled through with a single one handed switch, and and several color temperatures of white light. This one unit covers all the major wavelengths used in laboratory or crime scene evidence search and examination, with unparalleled convenience, flexibility, and power.




  • Maximum output power: —12W Ultra violet (UV)-LED: 410-415nm (3W), 375-380nm (3W),
  • 365-370nm (12W).
  • Maximum power of main engine: > 360W, continuous and adjustable output light.
  • Infrared LED: 730nm (5W), 850nm (5W), 940nm (5W)
  • Power Supply: 220VAC or 24VDC battery pack length: 2.5m,
  • Battery: The lithium iron phosphate battery pack is set outside the unit's case when operated in the field; capacity: 12Ah, charging voltage: 29.2V.
  • Output wavelength:
    • Laser: 532nm, 445nm, 405nm, CSSO (White), CSS1, CSS2.
    • LED visible light: 6500K (10W), 4500K (3W), 625-630nm (3W), 600-605nm (3W), 535-540 nm (3W), 465-470 nm (3W)
    • IR (Infrared): 940nm, 850nm, 730nm- appropriate camera filters and IR sensitive camera required to best use these wavelengths
    • UV (Ultraviolet): 415nm, 375nm, 365nm
  • Laser output mode: 400um multimode flexible fiber optic bundle, fiber length 2.5 meters.
  • LED white light is 6000K, with the integration design of ultra violet and infrared light sources.
  • Laser spot size: Spot diameter: 7cm at 0.5m location, Spot diameter: > 29cm at 0.5m location, Light spot diameter: + -.55cm at 5-meter location. Spot diameter: + -.28cm at 2m location.
  • Spot characteristics: Even light outputs with spot evenness >.-85%.
  • This is an all-in-one machine, the case is moisture proof and shockproof, and this one machine's output covers 18 wave bands.



Contact us for pricing and availability
